Description

DL-Mini01 Vertical electrophoresis tank, run two 8.3×7.3cm gels at the same time

This product is designed for vertical electrophoresis of a small amount of nucleic acid and protein samples.

The integrated design of the glass plate and the gasket ensures no glue leakage.

It can run two 8.3 × 7.3 cm gels at the same time.

The special glue-making device is simple and reliable in operation.

The silicone sealing pad is anti-aging and durable.

The cover can be opened and the power will be cut off automatically to ensure the safety of the experiment.

The limit function of the upper cover ensures that the positive and negative electrodes cannot be installed incorrectly.

99.99% high-purity platinum electrodes provide the best electrical conductivity, anti-corrosion, and aging resistance.

Equipped with a variety of rubber plate thickness specifications and sample combs to meet different experimental requirements.

It can be used together with the DL-ZY02.

Technical Parameters

Gel area: 8.3 × 7.3 cm

Gel thickness: 0.75, 1.0, 1.5 mm (optional)

Optional tooth number of sample comb: 10, 15

Glass size: Short glass plate (10.1 × 7.3 cm); long glass plate (10.1 × 8.2 cm)

Warranty: 1 Year
